The Cutting Material of Slitting Mill

Mainly sponge, pearl cotton, other foam materials can also be cut, for example: glass wool, EVA, if cut EVA requires hardness less than 70 degrees. Polyurethane material can also be cut. Replace the cutting blade with a serrated knife.

Alias of the Slitting Mill

The slitting mill is also called slicer,roll cutting machine chip opener, film forming machine, film opener.

Cutting Function of the Slitting Mill and How It Works

Cutting thick plates into thin sheets horizontally, while the straight cuts we commonly use are cut vertically.

The Precision and Error That Can Be Achieved by the Film Opener

The precision (thinnest) of pearl cotton can reach 0.2 mm, and the error can reach ± 0.2 mm. This has something to do with the master of the machine and the material to be cut. The machine may have a smaller error when it is adjusted, and it can be cut thinner. The higher the density of pearl cotton, the easier it is to cut thinner, and the thinner the density, the thinner it may become mesh.

Foamed Form of Foamed Material

The foam of pearl cotton is physical foam, and the sponge is chemical foam. Physical foaming changes shape, size, and substance does not change, while chemical foaming becomes another substance.

The Size and Model of the Slitting Mill

There are two types of opener, which can cut 1M and 1.2M. We can customize it shorter than this. The thickness of the material that can be opened by the film opener is 210MM. Those that exceed this thickness also need to be customized. The price is 50% -100% more expensive than now.

Working Mode and Degree of Automation of the Slitting Mill

Manual adjustment, digital display, display reference data.

What Are the Consumables of the Slitting Mill? Which Spare Parts Will Need to Be Replaced?

The knife belt and grinding wheel of the slitting mill are consumables, and the other ones are guaranteed for one year. In addition, the knife box needs to be replaced in 5 years, and frequently used in 3 years. The unit price of the knife box is 6,800 yuan.
